Product specification
| Product Name | P8 outdoor led billboard | Input Voltage | 100~240V, 50/60HZ |
| LED arrange | SMD3535 1R1G1B | Frame Frequency | > 60 Hz |
| Module size | 320x160 mm | Gray Scale/bit | 16 bit |
| Module resolution | 40x20 pixels | Refresh rate | 1920HZ/3840HZ/7680HZ |
| Drive Scan | 1/5 scan | Lifespan | 100000 hours |
| Cabinet size | 960x960mm | MTBF(Mean time between failures) | 10000 hours |
| Cabinet resolution | 120x120 pixels | Working temperature | -20℃~ +65 ℃ |
| Weight | 35 KGS | Humidity | 10% ~ 95% |
| Pixel density/sqm | 15625 pixels | Brightness control | 255 degree by software |
| IP rate | IP65 | Color Processing | (1024)×G(1024)×B(1024) |
| Power consumption/sqmt | Average: 400W Maximun: 1000W | Control method | Synchronous/Asynchronous |
| Brightness/sqm | 5000-5500 nits | Software brand | Novastar, Huidu, Colorlight, Mooncell or Linsn |
| View Angle(H/N) | 120/120 |
Product Features
IP65waterproofanddustproof,resistanttowindandrain/intensesun/extremecold
BrandedLEDchips,brandedpowersupply,highrefreshIC,lowattenuation,longlifespan
Point-by-pointcalibration,nocolordifferenceacrosstheentirescreen,minimalseams
Frontandrearmaintenancedesign,canbeservicedevenwhenplacedagainstawall,easymaintenancelater
Cabinetsizecanbeadjustedandproducedaccordingtomodulequantity,standardsizeis960*960mm
Lowpowerconsumption,energy-saving,naturalheatdissipationwithoutnoise,lowlong-termoperatingcost
Itsupportsmulti-splitscreen,picture-in-picture,livevideo,set-topboxprojection,andcanplaysubtitles+video+picturesatthesametime,withcompletefunctions.
Completelydustproofandwaterproof,withstablecomponentperformanceeveninextremecoldorheat.
HighBrightness:Theycanreachveryhighlevelsofbrightness,makingthemperfectlysuitableforoutdoorusewheretheymustremainvisibleevenindirectsunlight.
Our Service
Production Process
Packing and shipping
LED screen control system
Cooperation
FAQ
1.What lamp beads, power supply, and IC are used?
Answer: It is equipped with a first-line outdoor lamp bead + high-brush constant current driver IC + brand rainproof power supply, and the materials used are all engineering-grade configurations, with good stability, slow brightness decay and longer life.
2.What is the waterproof rating? Are you afraid of rain and heavy rain?
Answer: The whole screen is IP65 waterproof, the whole bottom of the module is glued, the box is sealed with silicone, and there is no problem with wind and rain, and it can be used outdoors around the clock.
3.Will there be color difference and blurred screens on the whole screen?
Answer: factory point by point brightness and color temperature calibration, the whole screen has no color difference or mottling, the seams are controlled very small, and the whole assembly is flat and uniform.
4.Can you customize any size?
Answer: Yes, the standard box is spliced, the length and width can be customized, and the door head can be made horizontally, vertically and squarely.
5.How do I change the word to video? Can the phone be controlled?
Answer: Equipped with a wireless control system as standard, computers and mobile apps can remotely send content, change pictures, videos, and scrolling subtitles at any time, without the need for people to come to the scene.
