Product specification
| Product Name | P10 outdoor fixed led screen | Input Voltage | 100~240V, 50/60HZ |
| LED arrange | SMD3535 1R1G1B | Frame Frequency | > 60 Hz |
| Module size | 320x160 mm | Gray Scale/bit | 16 bit |
| Module resolution | 32x16 pixels | Refresh rate | 1920HZ/3840HZ/7680HZ |
| Drive Scan | 1/2 scan | Lifespan | 100000 hours |
| Cabinet size | 960x960mm | MTBF(Mean time between failures) | 10000 hours |
| Cabinet resolution | 96x96 pixels | Working temperature | -20℃~ +65 ℃ |
| Weight | 35 KGS | Humidity | 10% ~ 95% |
| Pixel density/sqm | 10000 pixels | Brightness control | 255 degree by software |
| IP rate | IP65 | Color Processing | (1024)×G(1024)×B(1024) |
| Power consumption/sqmt | Average:400W Maximun: 1000W | Control method | Synchronous/Asynchronous |
| Brightness/sqm | 6000-6500 nits | Software brand | Novastar, Huidu, Colorlight, Mooncell or Linsn |
| View Angle(H/N) | 120/120 |
Product Features
IP65 full protection, rainproof, dustproof, lightning-proof, moisture-proof, suitable for year-round outdoor use
Front and rear maintenance design, can be serviced even when placed against a wall, easy maintenance later
Cabinet size can be adjusted and produced according to module quantity, standard size is 960*960mm
Low power consumption, energy-saving, natural heat dissipation without noise, low long-term operating cost
Supports remote screen control via mobile phone or computer, one-click video change, subtitle editing, scheduled playback
Completely dustproof and waterproof, with stable component performance even in extreme cold or heat.
High Brightness: They can reach very high levels of brightness, making them perfectly suitable for outdoor use where they must remain visible even in direct sunlight.
Our Service
Production Process
Packing and shipping
LED screen control system
Cooperation
FAQ
1.What lamp beads, power supply, and IC are used?
Answer: It is equipped with a first-line outdoor lamp bead + high-brush constant current driver IC + brand rainproof power supply, and the materials used are all engineering-grade configurations, with good stability, slow brightness decay and longer life.
2.What is the waterproof rating? Are you afraid of rain and heavy rain?
Answer: The whole screen is IP65 waterproof, the whole bottom of the module is glued, the box is sealed with silicone, and there is no problem with wind and rain, and it can be used outdoors around the clock.
3.Will there be color difference and blurred screens on the whole screen?
Answer: factory point by point brightness and color temperature calibration, the whole screen has no color difference or mottling, the seams are controlled very small, and the whole assembly is flat and uniform.
4.Can you customize any size?
Answer: Yes, the standard box is spliced, the length and width can be customized, and the door head can be made horizontally, vertically and squarely.
5.Is it OK to connect directly to 220V household electricity?
Answer: A small area can be directly used for 220V household use; It is recommended to use three-phase electricity for more than 10 square meters, which is more stable and more balanced.
