Product specification
| Product Name | P3.076 outdoor video wall rental | Input Voltage | 100~240V, 50/60HZ |
| LED arrange | SMD1921 1R1G1B | Frame Frequency | > 60 Hz |
| Module size | 320x160 mm | Gray Scale/bit | 16 bit |
| Module resolution | 80x40 pixels | Refresh rate | 1920HZ/3840HZ/7680HZ |
| Drive Scan | 1/13 scan | Lifespan | 100000 hours |
| Cabinet size | 640x640mm | MTBF(Mean time between failures) | 10000 hours |
| Cabinet resolution | 208x208 pixels | Working temperature | -20℃~ +65 ℃ |
| Weight | 13 KGS | Humidity | 10% ~ 95% |
| Pixel density/sqm | 105625 pixels | Brightness control | 255 degree by software |
| IP rate | IP65 | Color Processing | (1024)×G(1024)×B(1024) |
| Power consumption/sqmt | Average: 160W Maximun: 400W | Control method | Synchronous/Asynchronous |
| Brightness/sqm | 4500 nits | Software brand | Novastar, Huidu, Colorlight, Mooncell or Linsn |
| View Angle(H/N) | 160/160 |
Product Features
1.Lightweight one-piece die-casting, light in weight, high strength, no pressure on wall mounting / pole / rooftop. load-bearing
Twist-resistant, deformation-resistant, edge warp-free, outdoor exposure to wind and sun year-round without deformation
2.Super-wide viewing angles, consistent colors from multiple angles (up, down, left, right) without color shift
3. IP65 dust and water resistance for the whole machine, full protection front and back, rainproof, dustproof, moisture-proof, lightning-proof
4. Anti-static, interference-resistant circuits, no screen distortion or blackout during thunderstorms
5.It looks high-definition and delicate up close, and the picture quality is also very clear from medium to long distances, making it suitable for outdoor scenes with large crowds and close viewing.
6.Supports wireless mobile phone and remote computer publishing, allowing you to change videos, modify subtitles, and set scheduled power on/off anytime
7.Die-cast aluminum design, with high manufacturing precision, small joint gaps, good overall screen flatness; after assembly, the seams are almost invisible to the naked eye, giving a grand and tidy appearance overall.
Our Service
Production Process
Packing and shipping
LED screen control system
Cooperation
FAQ
1.How big is a 640×640 cabinet? How many square meters is a single cabinet?
A single cabinet is 640mm×640mm, which is 0.4096 square meters. The small cabinet layout is more flexible, making it easy to create irregular shapes, curved shapes, and precise sizes.
2. Is it troublesome to maintain later?
Modular design, which module is broken can be replaced separately, no need to disassemble and replace the whole screen, accessories are universal and cheap, and the maintenance cost is low in the later stage.
3. Can it be customized to my on-site size?
Yes, you can give me the length, width, and installation method, and I will help you accurately arrange the box, calculate the square, and issue a complete set of plans and quotations.
4. Is it in stock? How long is the delivery?
Regular inventory is in sufficient stock, and standard orders are shipped quickly; Customized size to help you schedule production, and the construction period will be clearly agreed upon for you.
5. Do you include door-to-door installation and commissioning?
It can include door-to-door measurement, solutions, installation, debugging, teaching operations, one-stop landing, you don't have to worry about any details.
6. How long is the warranty?
The whole machine has a 2-year warranty, lamp beads, power supply, and motherboard are guaranteed, and non-human damage can enjoy after-sales maintenance, and later lifelong cost maintenance.
7. What should I do if I can't operate it?
Free remote teaching operations, send tutorials, video guidance, teach you step by step to change content, set up programs, and include teaching and meetings.
