Product specification
| Product Name | P10 rental outdoor led display | Input Voltage | 100~240V, 50/60HZ |
| LED arrange | SMD3535 1R1G1B | Frame Frequency | > 60 Hz |
| Module size | 320x160 mm | Gray Scale/bit | 16 bit |
| Module resolution | 32x16 pixels | Refresh rate | 1920HZ/3840HZ/7680HZ |
| Drive Scan | 1/2 scan | Lifespan | 100000 hours |
| Cabinet size | 960x960mm | MTBF(Mean time between failures) | 10000 hours |
| Cabinet resolution | 96x96 pixels | Working temperature | -20℃~ +65 ℃ |
| Weight | 27 KGS | Humidity | 10% ~ 95% |
| Pixel density/sqm | 10000 pixels | Brightness control | 255 degree by software |
| IP rate | IP65 | Color Processing | (1024)×G(1024)×B(1024) |
| Power consumption/sqmt | Average: 320W Maximun: 800W | Control method | Synchronous/Asynchronous |
| Brightness/sqm | 6000-6500 nits | Software brand | Novastar, Huidu, Colorlight, Mooncell or Linsn |
| View Angle(H/N) | 120/120 |
Product Features
IP65 full protection, rainproof, dustproof, lightning-proof, moisture-proof, suitable for year-round outdoor use
Front and rear maintenance design, can be serviced even when placed against a wall, easy maintenance later
Lightweight die-cast aluminum, light weight, does not deform or warp, no load stress during installation
Low power consumption, energy-saving, natural heat dissipation without noise, low long-term operating cost
Supports remote screen control via mobile phone or computer, one-click video change, subtitle editing, scheduled playback
Completely dustproof and waterproof, with stable component performance even in extreme cold or heat.
High Brightness: They can reach very high levels of brightness, making them perfectly suitable for outdoor use where they must remain visible even in direct sunlight.
Modular & Seamless: The screens are built from smaller modules or cabinets that can be tiled together. This allows for the creation of extremely large screens of any size or shape with virtually no visible seams between panels.
Our Service
Production Process
Packing and shipping
LED screen control system
Cooperation
FAQ
1.How big is the 960×960 cabinet? How many squares is a cabinet?
The size of a single box is 960mm×960mm, a box is 0.9216 square meters, and the standard general die-casting aluminum box is not regular.
2.How many pixels are in a square?
100×100=10000 pixels per square;
3. What is the best viewing distance?
The best viewing distance is from 10 meters, and the farthest viewing distance is 150 meters, and the outdoor advertising is ultra-clear from a long distance.
4. What is the brightness? Can the Great Sun see clearly?
The standard high brightness ≥ 6500cd/㎡, and the outdoor strong light and direct sunlight at noon can be seen clearly, without whitening or blurring.
5. What is the refresh rate? Will there be water ripples when taking pictures?
High refresh rate of 3840Hz or above, mobile phone photos without flicker and water ripples, smooth video playback without smearing, and it is enough for live broadcasts and performances.
6. What lamp beads and ICs are used?
It adopts outdoor high-end full-color lamp beads + big brand driver IC, with good color reproduction, slow light fading, strong stability, and is not easy to break down when used outdoors all year round.
7. How many cabinets are there? Can the wall be installed?
Lightweight die-cast aluminum design, single box has a very light weight, ordinary walls, columns, and steel structures can be installed, with low load-bearing pressure, safe and worry-free installation.
