Product specification
| Product Name | P2.5 outdoor rental led display screen | Input Voltage | 100~240V, 50/60HZ |
| LED arrange | SMD1415 1R1G1B | Frame Frequency | > 60 Hz |
| Module size | 320x160 mm | Gray Scale/bit | 16 bit |
| Module resolution | 80x40 pixels | Refresh rate | 3840HZ/7680HZ |
| Drive Scan | 1/13 scan | Lifespan | 100000 hours |
| Cabinet size | 640x640mm | MTBF(Mean time between failures) | 10000 hours |
| Cabinet resolution | 208x208 pixels | Working temperature | -20℃~ +65 ℃ |
| Weight | 13 KGS | Humidity | 10% ~ 95% |
| Pixel density/sqm | 105625 pixels | Brightness control | 255 degree by software |
| IP rate | IP65 | Color Processing | (1024)×G(1024)×B(1024) |
| Power consumption/sqmt | Average: 160W Maximun: 400W | Control method | Synchronous/Asynchronous |
| Brightness/sqm | 4500 nits | Software brand | Novastar, Huidu, Colorlight, Mooncell or Linsn |
| View Angle(H/N) | 160/160 |
Product Features
1. Black matte frosted mask, enhances contrast, non-reflective under sunlight, clearer image quality
2. Module PCB is moisture-proof and deformation-resistant, stays stable under outdoor high and low temperatures. Waterproof glue applied to the bottom of the entire module.
3. Full silicone sealing for the cabinet, corners reinforced with waterproof strips
4. Heat dissipation optimization: Cabinet designed with convection heat dissipation holes, passive cooling without a fan, reduces failure points, dust-proof and noise reduction
5. Flatness optimization: Module with positioning pins, magnetic installation, seams ≤0.5mm, entire screen free of waves or noticeable seams
6.Color gamut calibration: Factory-calibrated brightness and color temperature point by point for each screen, no color difference, no blotchiness
7. Gray scale enhancement: 16-bit gray scale, retains dark scene details, makes promotional videos and logos look more premium
8. Compatibility: Supports 4K input, seamless switching between video/image/live broadcast, compatible with mobile phones, computers, and set-top boxes simultaneously
Our Service
Production Process
Packing and shipping
LED screen control system
Cooperation
FAQ
1. How to repair it if it breaks?
If you have any problems, contact us at any time, remotely troubleshoot, solve small problems remotely, send accessories directly for hardware problems, and replace them simply without professional technology.
2. Is it easy to disassemble and assemble? Is it suitable for stage rental?
With quick lock design, super fast disassembly and assembly, stable splicing, suitable for stacking and hanging, no problem in repeated use of performance rental.
3. Can I rent and sell dual-use?
Yes, it can be used for temporary stage rental and long-term fixed installation, which is very cost-effective.
4. Can the brightness be adjusted automatically? Will it be too bright at night to disturb the people?
You can install a light sensor probe, which automatically increases the brightness during the day and automatically lowers it at night, without hurting the eyes, disturbing the people, and without manual adjustment every day.
5. Will the humid salt spray on the beach rust and break the screen?
The cabinet design is die-casting aluminum, and the module is moisture-proof and glue-filled, which can be used normally by the seaside and rainy and humid areas, and is not easy to rust and dampen the lamp.
6. What lamp beads, power supply, and IC are used?
It is equipped with a first-line outdoor lamp bead + high-brush constant current driver IC + brand rainproof power supply, and the materials used are all engineering-grade configurations, with good stability, slow brightness decay and longer life.
