Product specification
| Product Name | P2.604 indoor led video wall screen | Input Voltage | 100~240V, 50/60HZ |
| LED arrange | SMD1515 1R1G1B | Frame Frequency | > 60 Hz |
| Module size | 250x250mm | Gray Scale/bit | 16 bit |
| Module resolution | 96x96 pixels | Refresh rate | 3840HZ/7680HZ |
| Drive Scan | 1/32 scan | Lifespan | 100000 hours |
| Cabinet size | 500x1000mm/500x500mm | MTBF(Mean time between failures) | 10000 hours |
| Cabinet resolution | 192x384 pixels/192x384 pixels | Working temperature | -20℃~ +65 ℃ |
| Weight | 13 KGS/8.5KGS | Humidity | 10% ~ 95% |
| Pixel density/sqm | 147456 pixels | Brightness control | 255 degree by software |
| IP rate | IP43 | Color Processing | (1024)×G(1024)×B(1024) |
| Power consumption/sqmt | Average: 320W Maximun: 800W | Control method | Synchronous/Asynchronous |
| Brightness/sqm | 500 nits | Software brand | Novastar, Huidu, Colorlight, Mooncell or Linsn |
| View Angle(H/N) | 160/160 |
Product Features
A. Stable performance, extremely slow decay, and 24/7 uninterrupted operation. low failure rates save you expensive labor repairs later.
B.Ultra-light and ultra-thin design, greatly reducing transportation and installation load.
C. 500x500 / 500x1000 cabinets are fully compatible for connection in all directions (top, bottom, left, and right).
D. Straight-edge cabinets and curved cabinets can be directly connected without changing locks, improving assembly efficiency.
E. Perfect for live broadcasting and social media "check-ins", elevating the premium image of advertised brands. Captures under camera and phone lenses with absolutely no water ripples or flicker; Color transitions are extremely delicate and smooth.
F. Supports inner and outer arc cylindrical shape connections to meet creative requirements.
G. Far exceeds the scanning frequency of ordinary screens, with no motion blur in dynamic images and smooth color transitions.
Our Service
Production Process
Packing and shipping
LED screen control system
Cooperation
FAQ
What is the difference between indoor and outdoor LED screens?
A: Indoor screen have a lower brightness to be comfortable for close-up viewing and do not require extensive weather protection. Outdoor screen feature high brightness to combat sunlight and have a high IP (Ingress Protection) rating for waterproofing and dust resistance. It is built to withstand harsh environmental conditions.
Is it OK to connect directly to 220V household electricity?
A: A small area can be directly used for 220V household use; It is recommended to use three-phase electricity for more than 10 square meters, which is more stable and more balanced.
How do I change the word to video? Can the phone be controlled?
A: Equipped with a wireless control system as standard, computers and mobile apps can remotely send content, change pictures, videos, and scrolling subtitles at any time, without the need for people to come to the scene.
Can I play and cast live in different regions?
A: It supports multi-split screen, picture-in-picture, live video, set-top box projection, and can play subtitles + video + pictures at the same time, with complete functions.
Will there be color difference and blurred screens on the whole screen?
A: Factory point by point brightness and color temperature calibration, the whole screen has no color difference or mottling, the seams are controlled very small, and the whole assembly is flat and uniform.
